Programming C & Y axis Lathes in G code with ProgramGuide

See Below for Timeline In this webinar we will have an opportunity to explore a real-world programming example that will take advantage of both C axis and Y axis functionality utilizing the TRANSMIT and TRACYL commands. From face drilling offset holes to peripheral milling of unique features. Once complete, attendees will have the confidence to apply this technology in their current challenges. Video Timeline 00:00:00 Intro 00:07:11 Overview 00:12:50 Tool Creation & Setting 00:20:30 Setting Offsets 00:21:33 Reference Documentation 00:23:17 Sample Part 1 00:25:15 Program Header 00:31:37 Groups & Tool Change 00:41:44 Op 1 - Turning 00:46:06 Op 2 - Axial Milling 00:53:47 Op 3 – Radial Milling 01:04:45 TRACYL 01:12:55 Op 4 - Radial Drilling 01:20:48 Op5 – Axial Drilling 01:25:36 TRANSMIT 01:29:31 Q&A Reference Doc - https://support.industry.siemens.com/cs/document/109760800/sinumerik-840d-sl-828d-fundamentals?dti=0&lc=en-WW #SINUMERIKnation #CNC #Siemens
