Back to 2006 | Teardown of Old Apple 110W Power Adapter (For Mac mini)

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: https://www.amazon.com/s?me=A31UM8SRXYVF2Z&marketplaceID=ATVPDKIKX0DER Introduction --------------------------------------------------------------- We've taken apart lots of different power adapters from Apple. But they are all new products released in recent years. Today, let's go back to 2006 and see what kind of power adapter Apple released that year. It's an original 110W power adapter for Mac mini from early 2006 to late 2009. Let's take it apart now. Bill of materials (BOM) ------------------------------------------ Model: A1188 Input Fuse: Littelfuse Safety X2 Capacitor: Carli Bridge Rectifier: GBU606 Film Capacitor: Carli PFC Controller: Infineon TDA4863G Primary MOSFET: Infineon IPA60R385CP, Infineon SPA11N65C3 Electrolytic Capacitor: Rubycon Master Control Chip: ON Semiconductor NCP1230 Schottky Diode: Diodes SBR20U150CT Operational Amplifier: STMicroelectronics TSM103WAI Chapter ---------------------------------- 0:00 Intro 1:25 Teardown 2:36 Analysis 6:01 Summary For more details. You can visit our website: https://www.chargerlab.com SOCIALS: Instagram：https://www.instagram.com/chargerlabs/ Facebook：https://www.facebook.com/chargerlab Twitter：https://twitter.com/chargerlab Telegram: https://t.me/ChargerLABchannel For Business Inquiries: info@chargerlab.com
