SOUTHWESTERN INDUSTRIES CNC VERTICAL MILL

https://www.machineryvalues.com/inventory/southwest-ind-dpm-v3-cnc-vertical-milling-machines-no-atc/167655/0 SOUTHWESTERN INDUSTRIES CNC VERTICAL MILL MODEL: DPM V3, S/N: 043BJ13032, NEW: 2004 SPECIFICATIONS: TABLES SIZE ...................... 50" X 10" T-SLOTS .......................... 3 x .63" x 2.48" TRAVELS: TABLE (X-AXIS) .................. 30" SADDLE (Y-AXIS) .................. 17" HEAD (Z-AXIS) ................... 21" QUILL DIAMETER ................... 4.13" SPINDLE TAPER .................... #40 NST SPINDLE SPEED RANGE .............. 200 - 5000 RPM SPINDLE CENTER TO COLUMN FACE .... 19.2" SPINDLE MOTOR .................... 5 HP MAX WEIGHT OF WORKPIECE .......... 1,320 LBS TABLE HEIGHT FROM BED BOTTOM ..... 38" MAX SPINDLE NOSE TO TABLE ........ 21" MIN HEIGHT ....................... 85" MAX HEIGHT ....................... 100" WIDTH OF MACHINE (incl table)..... 73" APPROXIMATE MACHINE WEIGHT ....... 4,100 LBS. EQUIPPED WITH: PROTO-TRAK MODEL: VM CONTROL UPDATED 2021 REMOTE GO SWITCH BALL SCREWS & AC SERVO MOTORS FOR X,Y & Z AXES YASKAWA SPINDLE DRIVE ELECTRONIC HANDWHEELS TRACKING TORQUE-RITE POWER DRAW BAR HARDENED & GROUND BOX WAYS AUTOMATIC LUBRICATION SYSTEM COOLANT SYSTEM 5 HORSE POWER SPINDLE MOTOR & INVERTER INSPECT UNDER POWER IN OUR NEW JERSEY WARHOUSE
