Parallax Occlusion Intersection (Grass Pixel Shader) Close-ups

More (4K) footage of my shader because youtube compression makes it hard to see. The algorithm is described at 1:15 here: https://youtu.be/yLHk82-Df9M Quality settings: Using a large patch is the most flexible, as it can recreate any target mesh without obvious "tiling", but the memory usage can be ridiculous with best quality. A smaller patch has more "tiling" but that can be reduced by redrawing it at different angles, which is alright for grass/fur. In this video the small patch is 1/64 the size of the large patch (in terms of number of grass blades). Best quality, large patch: 2048x2048, 250 maps (!!!) Lower quality, large patch: 1024x1024, 50 maps Lowest quality, large patch: 512x512, 20 maps Best quality, small patch: 256x256, 250 maps Lower quality, small patch: 128x128, 50 maps (With only depth maps, this could be similar memory to a single 1024x1024 texture) In this video all the maps are both depth and color maps, but for many applications you can save 3/4 of the memory by just using a single color map (I did that for fur: https://www.youtube.com/watch?v=BzsmOUpkvUw ). In terms of performance it's similar to parallax occlusion mapping. Having to sample from 3 maps makes it worse, but the maps are more well aligned with the view ray (think POM looking almost straight down) which helps with caching and step count.
