7 Segment Digital Counter Circuit using 4026 and 555 IC | Proteus Simulation

Simple Digital counter circuit using 7 Segment Display About This Video:- The 7-segment display, also written as “seven segment display”, consists of seven LEDs (hence its name) arranged in a rectangular fashion as shown. Each of the seven LEDs is called a segment because when illuminated the segment forms part of a numerical digit (both Decimal and Hex) to be displayed. An additional 8th LED is sometimes used within the same package thus allowing the indication of a decimal point, (DP) when two or more 7-segment displays are connected together to display numbers greater than ten. Each one of the seven LEDs in the display is given a positional segment with one of its connection pins being brought straight out of the rectangular plastic package. These individually LED pins are labeled from a through to g representing each individual LED. The other LED pins are connected together and wired to form a common pin. In this Tutorial, I will show you how to make a Digital Counter using 7 Segment Display Note: Watch this Video Completely before attempting this Method. Materials Required : 1. 4026 IC 2. 555 IC 3. Resistor - 10K, 100K, 1uF 4. Button 5. Seven Segment Display 6. Capacitor - 1uF Circuit Diagram : - https://drive.google.com/open?id=1ypDhik05vwsR_fje9R9fnkakRgNZxYpv #7segementdisplay #digitalcounter #countercircuit #555ic #4026ic #ElectronicsProjects #DIY #LifeHacks #HowtoMake your queries:- How to make digital counter circuit? How to make seven segment based counter? How to make 555 IC based Project? How to make 4026 based Project? **************************************************** Thanks for Watching : LIKE | COMMENT | SHARE | SUBSCRIBE **************************************************** Other Interesting Project Videos Links: 3 DOF Pick and Place Robotic ARM : http://bit.ly/2yd2DX0 Scrolling Message Display using Bluetooth : http://bit.ly/2yd2DX0 Pollution Monitoring System using IoT : http://bit.ly/2yzstnt Solar Inverter 12V to 220AC : http://bit.ly/2A4T7a9 **************************************************** Connect with InnoSpire Subscribe : http://bit.ly/2A4nugF Website : http://www.htslabz.com Mail us at: htslabz@gmail.com Facebook : http://bit.ly/2EbJ5HZ Wastapp : 7780280714 *************************************************** About InnoSpire Channel : InnoSpire is a YouTube Channel, Where you will fine Technological Videos related to Free DIY Project, Tutorials, Tech Updates and Many More. New Videos are Posted Every Day. Videos are in Language : Hindi, Telugu and English ************************************************** Music Provided by NCS Release- JPB - High _NCS Release_
