VSD - 10 Bit DAC using Sky130 Part 1 - Overview and project implementation flow

https://www.vlsisystemdesign.com/vsd-intern-free-webinar/ The webinar aims to design a 10-bit potentiometric Digital to Analog Converter using end-to-end Open-source EDA tools. The target is to design 10-bit potentiometric DAC with 3.3v analog voltage, 1.8v digital voltage and 1 off-chip external voltage reference using sky130nm technology node. In real world, most of the data available is in the form of analog in nature. We have two types of converters analog to digital converter and digital to analog converter. These two converting interfaces are essential to obtain the required operations of a processor to manipulate the data of digital electronic equipment and an analog electric equipment. Digital to Analog Converter (DAC) is a device that transforms digital data into an analog signal in order to interact with the real world. The digital signal is represented with a binary code, which is a combination of bits 0’s and 1’s. The digital data can be produced from a microprocessor, Field Programmable Gate Array (FPGA), or Application Specified Integrated Circuit (ASIC). There are two commonly used DAC conversions – Weighed resistors method and R-2R ladder network method. Applications of a DAC: audio amplifier, video encoder, display electronics, data acquisition systems, calibration, Digital potentiometer. This webinar will cover 1) Overview of DAC Why DAC? Background and Principle of Operation. Implementation Aspects and Challenges. Evaluation Parameters. 2) Project Design Specs and DAC Circuit Circuit Behaviour Expected Input Output Characteristics. 3) Project Flow –Analog IP – Hands-on Flow of Steps for Analog IP design. Tools Required Setup of Tools Libraries Required Setup and linking Libraries. All the best and happy learning
