Dilation(Complete Code & Explanation) | Image Processing | MATLAB

USECASE Question: Suppose you want to remove all the circuit lines from the original circuit image, leaving only the rectangular outlines of microchips. Prerequisite: Prerequisite: https://www.mathworks.com/help/images/ref/imerode.html Image Erosion | MATLAB (with Animation) https://www.youtube.com/watch?v=cp540HLuXRQ Dilate image using imdilate: https://www.mathworks.com/help/images/ref/imdilate.html Code: %% %Reading the Image clc clear all close all I=imread('circbw.tif'); imshow(I); %% %Structural Element SE = ones(30,30); B=imerode(I,SE); %% %Plotting the Images subplot(1,2,1); imshow(I); title('Original Image'); subplot(1,2,2); BW3 =imdilate(B,SE); imshow(BW3) title('Detecting Rectangles'); #ImageProcessing #DIP #DSP
