Current Sensor Experimenting for Grid-Tie Solar

http://300mpg.org/2017/11/13/sensing-current-for-solar/ As always, there's more details about this video at the blog. Please click the link in this description for more on this project! I begin experimenting with using a Current Transducer to measure how much power the solar panels on my garage are creating. This is hooked up through a few resistors to an Arduino. The Arduino then positions a servo to act as an analog ammeter gauge. As I keep going on this project, I'll use the output of the Arduino to control an EVSE (Electric Car Charging station) to match the rate of charging of the electric car to the rate of power produced by the solar panels. That way, I'll have an electric car which is 100% solar charged and it will NOT draw power from the grid if clouds cover the sun. Please see the link for details.
